Operating voltage (DC): 0.3V ~ 30 V
Current: 100A
Power: 330W
- CC mode
Setting range:
Range H: 0 A ~ 100A
Range M: 0 A ~ 10A
Range L: 0 A ~ 1A
Setting accuracy: ±(0.2 % of set + 0.1 % of f.s) + Vin/ 150 kΩ
Ripple: rms: 8 mA/ p-p: 80mA
- CR mode
Setting range
H: 346.5 S ~0 S
M: 34.65 S ~ 0 S
L: 3.465 S ~0 S
Setting accuracy: ±(0.5 % of set + 0.5 % of f.s) + Vin/ 150 kΩ
- CV mode
Setting range:
H: 0 V ~ 31.5 V
L: 0 V ~ 4.2 V
Setting accuracy: ±(0.2 % of set + 0.2 % of f.s)
- CP mode
Setting range:
Range H: 0 W ~ 346.5 W
Range M: 0 W ~ 34.65 W
Range L: 0 W ~ 3.465 W
Setting accuracy: ±(2.5 % of f.s )
Measurement function: V, A, P
Pulse function: Frequency setting range 1 Hz ~ 20 kHz
Other functions: Sequence, Remote sensing, Protection function (OVP, OCP, OPP, UVP)
Communication: GPIB, RS232C, USB
Accessories:
Power cord × 1 pc. (with plug, Length: approx. 2.4 m),
Load input terminal cover × 1 piece (2 lock plates provided),
Set of screws for the load input terminal × 2 sets (bolts, nuts, and spring washers),
Setup guide × 1 piece(Japanese, English),
Quick Reference(Japanese:1 piece, English:1 piece), CD-ROM × 1 piece
