- Input:
Nominal input: 380 Vac to 480 Vac (3 phase line voltage)
Nominal frequency: 50 Hz to 60Hz
- Output
Setting AC voltage: 0 V to 157.5 V / 0 V to 315.0 V
Setting accuracy: ±(0.3 % of setting + 0.3 V), ±(0.3 % of setting + 0.6 V)
Maximum current:
Single-phase output: 60A/ 30A
Three-phase output: 20A/ 10A
Power:
Single-phase output/ three-phase output: 6 kVA
Single-phase three-wire output: 4 kVA
Frequency
Setting range: 1 Hz to 5 kHz (5 kHz -3dB, <40 Hz derating required)
DC voltage:
Setting range: -222.5 V to +222.5 V / -445.0 V to +445.0 V
Accuracy: ±(0.05 % of setting +0.1 V)
Power capacity: 6 kW
- Output Voltage Stability:
Line regulation: Within ±0.1 %
Load regulation:
Within ±0.1 V/ ±0.2 V(1 Hz to 100 Hz)
Within ±0.3 V/ ±0.6 V(100.1 Hz to 500 Hz)
Within ±1 V/ ±2 V(500.1 Hz to 1 kHz)
Ripple noise: ≤ 0.25 Vrms
- Interfaces: RS232C, USB, LAN, GPIB (Option)
- Measurement: Voltage Rms, Current Rms, Current peak, Active power, Harmonic,...
- Accessories: Cable tie (4 pcs.), External control(DIGITAL I/O) connector (1 pc.), Read This First! (1 copy), Quick Reference(1 sheet), CD-ROM (1 disc), Safety Information (1 copy), Heavy object warning label (1 pc.)
