Nominal input rating: 200 V ~ 240 V, 50 Hz to 60 Hz, three-phase
Output power: 40 kW
Output voltage: 500 V
Output current: 80 A
Voltage setting accuracy: ± (0.2 % of rtg +50 mV)
Current setting accuracy: ± (1.5 % of rtg +500 mA)
Display function:
Voltmeter:
Maximum display: 99.99 (fixed decimal point)
Display accuracy: ± (0.2 % of rdng +5 digits) at 23 °C ± 5 °C
Ammeter :
Maximum display: 999.9 (fixed decimal point)
Display accuracy: ± (0.6 % of rdng +5 digits) at 23 °C ± 5 °C
Protection functions: Overvoltage, Overcurrent, Overheat, Input open-phase, Fan failure,...
Interface: RS232C, GPIB (option), USB (option)
Accessories:
Output terminal bolt set, Heavy object warning label, J1/J2 connector kit, Chassis connection wire
Plastic sleeves for the output terminal set, Quick Reference (base model), Setup Guide, Safety Information, CD-ROM
