Digital input
Number of isolated bits: 32-bit
Maximum input voltage range: 24V
Digital logic levels
High: 10 to 24 V
Low: 0 to 2 V
Input resistance: 24 kΩ at 0.75 W
Input current (maximum): 1.5 mA per bit
Maximum transient voltage: 1250 V
Digital output
Number of isolated bits: 32-bit
External supply voltage range: 5 V to 35 V
Maximum transient voltage: 1250 V
Storage temperature: –20 to +70 °C
Operating temperature: 0 to +55 °C
Connector type: 100-pin SCSI-II connector
Dimensions (W × D × H): 120.00 × 182.40 × 44.00 mm
Remote interface: Hi-Speed USB 2.0
