Frequency range: 10 MHz to 18 GHz
Power range: –60 to +20 dBm
Connector: N-type (m), 50 Ω
Measurement speed
Normal: 20 readings/s
x2: 40 readings/s
Fast: 110 readings/s
Buffered (50 readings): 1000 readings/s
Dimensions (LxWxH): 163.75 mm x 46.00 mm x 35.90 mm
Weight: 0.262 kg
Operating environment
Temperature: 0 to 55 °C
Humidity: Up to 95% relative humidity at 40 °C (non-condensing)
Altitude: Up to 4600 m (15,000 ft)
Storage and shipment
Environment Sensor should be stored in a clean, dry environment
Temperature: –30 to +70 °C
Humidity: Up to 90% relative humidity at 65 °C (non-condensing)
Altitude: Up to 4600 m (15,000 ft)
Other
Current requirement: 200 mA max (approximately)
Cable: USB 2.0 Type A to 5-pin Mini-B
Programmability: SCPI, Keysight VEE, LabVIEW, Microsoft® Visual Basic
Safety and EMC compliance:
IEC 61010-1:2001/EN 61010-1:2001(2nd edition)
IEC 61326:2002/EN61326:1997+A1:1998+A2:2001+A3:2003
Canada: ICES-001:2004
Australia/New Zealand: AS/NZS CISPR11:2004
Standard-shipped accessories
Trigger cable BNC Male to SMB female 50 Ω, 1.5 m
Power sensor cable: 1.5 m, 3.0 m, or 5.0 m
