- Voltage DC:1000.0mV, 10.000 V, 100.00V, 1000.0V /0.09%
- Voltage AC (True RMS): 1000.0mV, 10.000V, 100.00V, 1000.0V /1%
- Current DC: 1000.0μA, 10000μA, 100.00mA, 440.0mA, 10.000A /0.1%
- Current AC (True RMS): 1000.0μA, 10000μA, 100.00mA, 440.0mA, 10.000A/
- Resistance:1000.0Ω, 10.000kΩ, 100.00kΩ, 1000.0kΩ, 10.000MΩ, 100.00MΩ /0.3%
- Diode: 1V/ 0.3%
- Capacitance: 1000.0 nF, 10.000 μF, 100.00 μF,1000.0 μF, 10.000 mF /1.2-2%
- Frequency:100.00 Hz, 1000.0Hz, 10.000kHz, 100.00kHz, 1000.0kHz /0.03%
- Thermocouple type: –40 to 1000 °C/ 1% (option)
- Switch counter: yes
- 4-20mA % Scale: Yes
- PC connectivity: IR-USB (option)
- Connectivity: IR-to-Bluetooth (option)
Power supply: Battery 4 x 1.5 V AAA
Dimensions: (H x W x D): 193.8 mm x 92.2 mm x 58.0 mm
Included Accessories: Test Lead Set; Quick Start Guide; 4 x 1.5 V Batteries; Certificate of Calibration
Datasheet
Brochures
Optional Accessories
U1169A: Test Probe Leads (with 19-mm tips and 4-mm tips)
U1174A: Carrying case, soft
U1172A: Transit case for handheld DMM, aluminum-clad
U1164A: Test probes, fine tip
U1163A: Grabbers, SMT
U1162A: Alligator clip
U1183A: Probe, air
U1583B: AC current clamp
U1182A: Surface probe, industrial
U1181A: Immersion probe type K
U1171A: Magnetic hanging kit
U1186A: Thermocouple (K-type, 1m) and adapter
U1184A: Adaptor, temperature probe
U1187A: Thermocouple (K-type, 3.5m) and adapter
U1176A: LED flash light
U1179A: IR connectivity bracket for U1240 Series HHDMM
U1177A: Infrared (IR)-to-Bluetooth class 2 (10meter) adapter
U1168B: Test lead kit
U1117A: Infrared (IR)-to-Bluetooth class 1 (100meter) adapter with Mfi
U1115A: Bluetooth class 1 (100meter) remote logging display
U1118A: Remote connectivity kit (100meter) with U1115A and U1117A
U1173B: IR-USB cable, all U1200 series handheld multimeter VOLT: DC 3.3V - 5V
