• Frequency: 9 kHz to 44 GHz
• Test port connectors: NMD 2.4 mm (m)
• Spectrum analyzer: Spectrum, channel power, adjacent power, occupied bandwidth, analog demodulation, tune and listen
• Frequency span: Resolution: 1 Hz
• Frequency reference: -10 to 55°C
• Phase noise: Stability, SSB phase noise at 1 GHz
• Resolution bandwidth (RBW), range (-3 dB bandwidth):
Zero span: 10 Hz to 5 MHz: 1, 3, 10 sequence
Non-zero span: 1 Hz to 5 MHz: 1, 1.5, 2, 3, 5, 7.5, 10 sequence
• Video bandwidth (VBW): 1 Hz to 5 MHz in 1, 1.5, 2, 3, 5, 7.5, 10 sequence
• Displayed average noise level (DANL): RMS detection, log averaging, reference level of -20 dBm, normalized to 1 Hz RBW
• Third order intermodulation distortion (TOI): Two -20 dBm signals, 100 kHz spacing at input mixer, – 10 to 55°C
• Real-time spectrum analyzer (RTSA):
Maximum real-time bandwidth: 10 MHz
Resolution bandwidth: 1 Hz to 500 kHz
• Analysis bandwidth: Maximum bandwidth 10 MHz
• Dimension H x W x D: 292 x 188 x 72 mm (11.5" x 7.4" x 2.8")
• Battery: Lithium ion, 10.8 V, 4.6 A-h, 3.5 hours (typical)
• Weight: 3.2 kg or 7.1 lb. including battery
• What's Included:
AC/DC adapter
Localized power cord
Battery –rechargeable Li Ion
LAN cable
Soft carrying case with backpack and shoulder strap
Quick Reference Guide
