Maximum output range: 21 V / 500 mA (DC)
Output connector: BNC
Output/residual resistance: 10 Ω nominal (2-wire), 0.3 Ω nominal (4-wire. 4-wire connected inside of filter)
Small signal bandwidth: 23 Hz nominal (2-wire), 8 Hz nominal (4-wire)
Source noise
Voltage
0.1 to 10 Hz: Same as voltage specification
10 to 20 MHz: 10 μVrms, 1nVrms√Hz at 10 kHz (20 V / 100 mA range, 50 Ω load)
Current
0.1 to 10 Hz: Same as current specification
10 to 1 MHz: 8 μArms (20 V/1 A range, 2 Ω load)
Maximum capacitive load: 50 μF (for 4-wire)
Dimensions: 41 mm H x 58.2 mm W x 141.5 mm D
Weight: 0.3 kg
