Frequency Range: 10 MHz to 40 GHz
Power range: −70 to +20 dBm
Connector type: 2.92 mm (male)
Maximum power
Average: +26 dBm
Peak: +29 dBm for < 10 µs duration
Voltage: ≤ 10 VDC
Zero and calibration: Internal zero and calibration supported
Maximum sampling rate: 20 Msamples/second, continuous sampling
Single shot bandwidth: 5 MHz
Minimum pulse width: 250 ns
Rise/fall time: ≤ 100 ns
Maximum capture length:
1 s (decimated)
6.5 ms (at full sampling rate)
Maximum pulse repetition rate: 2 MHz (based on 10 samples/period)
