Frequency
Range: 1 MHz to 3 GHz
Resolutionz: 1 kHz 1
Oscillator level
Cable length = 1 m
Power range (When 50 Ω LOAD isconnected to test port)
–40 dBm to 1 dBm
Current range (When SHORT is connected to test port)
0.0894 mArms to 10 mArms
Voltage range (When OPEN is connected to test port)
4.47 mVrms to 502 mVrms
Uncertainty (When 50 Ω LOAD is connected to test port)
(23 °C ± 5 °C)
± 2 dB (frequency ≤ 1 GHz)
± 3 dB (frequency > 1 GHz)
(5 °C to 40 °C)
± 4 dB (frequency ≤ 1 GHz)
± 5 dB (frequency > 1 GHz)
Resolution 0.1 dB (When the unit is set at mV or mA, the entered value is rounded to 0.1 dB resolution.)
Cable length = 2 m (When option 002 is used)
Power range Subtract the following attenuation from the power
Dimensions, weight:
Weight Main unit: 13 kg, test head: 250 g with plate
