Bandwidth:
70 MHz (base bandwidth)
200 MHz (D1200BW2A)
Analog channels: 4
External trigger: Back panel input (not displayed)
Sample rate per channel (max):
2 GSa/s (one- or half-channel1 operation)
1 GSa/s (three- or four-channel operation)
Memory depth per channel (max):
2 M points (one- or half-channel1 operation)
1 M points (three- or four-channel operation)
WaveGen: 20-MHz function generator
Bode plot: Standard
Waveform update rate: 200,000 waveforms per second
Serial protocol analysis: Standard : I²C, SPI, UART/RS-232, CAN, LIN
Segmented memory: Standard
Mask/limit testing: Standard
Built-in training signals: Standard
Integrated digital voltmeter: Standard
Frequency counter: Standard
Waveform math: Add, subtract, multiply, divide, FFT (magnitude and phase), low pass filter
Automatic measurements: 14 amplitude, 14 timing, and 4 pulse count measurements
Display: 7-inch TFT LCD WVGA
Connectivity: USB 2.0 (host and device), LAN
