AC Input
Connections: L1, L2, PE (1-phase with protective earth)
Voltage: 100 VAC -15% to 240 VAC +10%
Maximum Phase Current (A RMS)
19.7 A (100 VAC, 1-phase)
17.9 A (110-130 VAC, 1-phase)
10.4 A (190-240 VAC, 1-phase)
Frequency: 50/60 Hz
DC Power Ratings
• Voltage: 0 – 300 V
• Current: 0 – 5 A
• Power: 1.5 kW
Output Ripple and Noise
• CV rms: 45 mV
• CV peak-to-peak: 180 mV
Load Regulation
• Voltage: 32 mV
• Current: 6 mA
Line Regulation
• Voltage: 30 mV
• Current: 2.5 mA
Voltage Programming Accuracy
• Voltage: ≤ 150 mV
Current Programming Accuracy
• Current 0.1%+: 10 mA
Voltage Measurement Accuracy
• Voltage: ≤ 150 mV
Current Measurement Accuracy
• Current: ≤ 10 mA
Transient Response
• Recovery time: ≤ 2 ms
• Settling band: 1.5 V
*For detailed specifications, please refer to the Datasheet.
*Images for illustration purposes only.
