Applicable instruments: E4980A/AL, E4981A, E4990A
Frequency: DC to 13 MHz
Maximum voltage: ±42 V peak max. (AC+DC)
Operating temperature: 0 to 55°C
Terminal connector: 4-Terminal pair, BNC
DUT connection: 4-Terminal
Dimensions (approx.): 124 (W) x 31 (H) x 62 (D) mm
Weight (approx.): 205 g
Furnished accessories: Description: P/N x Qty.
Module for axial lead: 16061-70022 x 2
Module for radial lead mounting on fixture: 16061-70021 x 2
Module for short radial lead: 16047-65001 x 2
Operating note: 16047-90011 x 1
Option:
16047A-701: Add Shorting plate P/N (ordering number) 16047-00640
