Output type: PNP
Sensing distance: 5 – 300 mm (100 × 100 mm white matte paper)*
Setting distance: 40 – 300 mm (100 × 100 mm white matte paper)
Light source: Red LED
Sensitivity adjustment: Automatic push-button
Response time: Max. 1 ms (max. 1.2 ms for frequency switching type, max. 2 ms for M61 only)
Operation mode: Light-ON / Dark-ON
Indicator: ―
Control output
Output current:
NPN: Max. 100 mA (24 V)
PNP: Max. 100 mA (24 V)
Residual voltage: ≤ 1 V
Display
Digital display: Red 7-segment LED, 3 digits
Protection circuit
Reverse polarity protection
Overcurrent protection
Surge protection
Power supply
Supply voltage: 12 – 24 VDC ±10%, ripple < 10%
Current consumption: Max. 37 mA
Environmental specifications
Protection rating: IP67
Ambient light:
Lamp: ≤ 5,000 lux
Sunlight: ≤ 20,000 lux
Operating temperature: -20 to +55 °C (no freezing)
Ambient humidity: 35 – 85% RH (no condensation)
Vibration resistance: 10 – 55 Hz, 1.5 mm double amplitude (2 hours each axis)
Shock resistance: 1,000 m/s², 6 times in X, Y, Z directions
Mechanical
Housing material: Glass fiber reinforced plastic
Accessories: ―
Weight: Approx. 55 g (including 2 m cable)
