Application: Dosing & consumption
Process Medium:
Diesel, Skydrol, AdBlue, odorant
(Less) lubricating
Low viscosity
Attributes:
Stainless steel body
Stainless steel ball bearing
Small tolerances
Technical Data – Sizes
Measuring Range(l/min): 0.5 up to 75.0
K-Factor(pulses/l): 475
max. Pressure(bar/psi): 420 [6,000]
Frequency(Hz): 4 up to 560
Weight(kg): 8.5
Technical Data – General
Measuring Accuracy: Up to ±0.1 %
Repeatability: ±0.05 % (under the same conditions)
Linearity: ±1.5 % of actual flow (viscosity ≥ 5 mm²/s) | ±2.5 % of actual flow (viscosity ≥ 5 mm²/s for ZHM 01/3)
Materials
Housing: as per DIN 1.4305 [AISI 303], 1.4404 [AISI 316L]
Gears: as per DIN 1.4122
Bearing: Stainless steel ball bearing
Seals: FKM, PTFE (others on request)
Medium Temperature: -40 °C up to +180 °C [-40 °F up to +356 °F]
Dimensions: See dimensional drawing (In details)
See datasheet for choosing suitable configurations!
