Technical Data – Sizes
HM types: HM 030 TRI
Measuring Range (l/min): 35 - 400 L/min
K-Factor (pulses/l): 130 (pulses/l)
Max. Pressure: 10 [145] (bar/psi)
Max. Frequency (Hz): 1,850 Hz
Weight: 3.2 kg
Technical Data – General
Measuring Accuracy: ±1%
Repeatability: ±0.05 % (under the same condition)
Linearity: ±1 % of actual flow
Viscosity Range: 1 mm2/s
Materials
Housing: as per DIN 1.4404 [AISI 316L]
Wheels: as per DIN 1.4460 [AISI 329]
Bearing: PTFE
Inner seal: FKM
Medium Temperature: -40 °C up to +150 °C [-40 °F up to +302 °F]
Dimensions: See dimensional drawing
See datasheet for choosing suitable configurations!
