KEM HM 005 R Turbine Flow Meters with BSPP Threads (0.8 - 6 L/min) | EMIN.CO.TH

Turbine Flow Meters
KEM HM 005 R Turbine Flow Meters with BSPP Threads (0.8 - 6 L/min)

Stay Updated with Offers

Get exclusive volume discounts, bulk pricing updates, and new product alerts delivered directly to your inbox.

By subscribing, you agree to our Terms of Service and Privacy Policy.

Quick Support

Direct access to our certified experts

Product image

KEM HM 005 R Turbine Flow Meters with BSPP Threads (0.8 - 6 L/min)

ManufacturerKEM(View more products from this manufacturer)

ModelHM 005 R

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Technical Data – Sizes

HM types: HM 004 R

Measuring Range (l/min): 0.8 - 6 L/min

K-Factor (pulses/l)

With > 1cst: 17,800 pulses/l

With > 8cst: 17,800 pulses/l

Max. Pressure: 630 [9,140] (bar/psi)

Max. Frequency (Hz)

With > 1cst: 1,740 Hz

With > 8cst: -

Weight: 0.4 kg

Technical Data – General

Measuring Accuracy: ±1%

Repeatability: ±0.05 % (under the same condition)

Linearity: ±1 % of actual flow

Measuring Span: Standard: 1:10. Extended: on request

Viscosity Range: 0.8 up to 30 mm2/s

Materials

Housing: as per DIN 1.4404 [AISI 316L], others on request

Wheels: as per DIN 1.4460 [AISI 329], others on request

Bearing: Tungsten carbide sleeve bearing

Medium Temperature: -60 °C up to +350 °C [-76 °F up to +662 °F]

Dimensions: See dimensional drawing

See datasheet for choosing suitable configurations!

Dimensional Drawing

Datasheet

Manual
