Width: 8.5 mm (0.335 in)
Height: 17 mm (0.669 in)
Length: 26.5 mm (1.043 in)
Tolerance: 5 %
Dielectric: Polypropylene (PP)
Lead Style: Straight
Capacitance: 0.047 uF
Lead Spacing: 22.5 mm (0.886 in)
Lead Diameter: 0.8 mm
Qualification: AEC-Q200
Number of Pins: 2 Pin
Capacitance - nF: 47 nF
Capacitance - pF: 47000 pF
Termination Style: Radial
Voltage Rating AC: 650 VAC
Voltage Rating DC: 1.6 kVDC
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
