Width: 8.5 mm (0.335 in)
Height: 14.5 mm (0.571 in)
Length: 18 mm (0.709 in)
Tolerance: 5 %
Dielectric: Polypropylene (PP)
Lead Style: Straight
Capacitance: 0.01 uF
Lead Spacing: 15 mm (0.591 in)
Lead Diameter: 0.8 mm
Number of Pins: 2 Pin
Capacitance - nF: 10 nF
Capacitance - pF: 10000 pF
Termination Style: Radial
Voltage Rating AC: 900 VAC
Voltage Rating DC: 2.5 kVDC
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
