Karg MKT720 Heating and Cooling Chambers (-70 ~180 °C , 5000W)

Performance Data Temperature

Temperature range [°C]: -70…180

Temperature variation depending on setpoint [± K]: 0.3…2

Temperature fluctuation depending on setpoint [± K]: 0.1…0.5

Average heating-up rate according to IEC 60068-3-5 [K/min]: 4.5

Cooling down time from 180 °C to -40 °C [min]: 120

Average cooling down time according to IEC 60068-3-5 [K/min]: 4.0

Max. heat compensation at 25 °C [W]: 5000

Electrical data

Rated Voltage [V]: 400

Power frequency [Hz]: 50

Nominal power [kW]: 13

Unit fuse [A]: 32

Phase (Nominal voltage) [ph]: 3~

Outer dimensions

Width net [mm]: 1580

Height net [mm]: 2005

Depth net [mm]: 1140

Wall clearance back [mm]: 300

Wall clearance sidewise [mm]: 200

Viewing window width [mm]: 508

Viewing window height [mm]: 300

Doors

Unit doors: 1

Internal Dimensions

Width [mm]: 1200

Height [mm]: 1020

Depth [mm]: 600

Further Dimension

Interior volume [L]: 734

Net weight of the unit (empty) [kg]: 610

permitted load [kg]: 160

Load per rack [kg]: 40

Environment-specific data

Sound-pressure level [dB(A)]: 65

Fixtures

Number of shelves (std./max.): 1/11
