Performance Data Temperature
Temperature range 5 °C above ambient temperature to [°C]: 300
Temperature variation at 150 °C [± K]: 1.7
Temperature fluctuation at 150 °C [± K]: 0.4
Heating-up time to 150 °C [min]: 19
Recovery time after 30 seconds door open at 150 °C [min]: 6
Air change data
Air change (approx.) at 150 °C [x/h]: 9
Electrical data
Rated Voltage [V]: 230
Power frequency [Hz]: 50 / 60
Nominal power [kW]: 2.5
Unit fuse [A]: 16
Phase (Nominal voltage) [ph]: 1~
Outer dimensions not incl. fittings and connections
Width net [mm]: 810
Height net [mm]: 962
Depth net [mm]: 786
Wall clearance back [mm]: 160
Wall clearance sidewise [mm]: 100
Internal Dimensions
Width [mm]: 650
Height [mm]: 780
Depth [mm]: 512
Further Dimension
Interior volume [L]: 259
Net weight of the unit (empty) [kg]: 96
Permitted load [kg]: 270
Load per rack [kg]: 40
Environment-specific data
Energy consumption at 150 °C [Wh/h]: 465
Fixtures
Number of shelves (std./max.): 2 / 8
