Performance Data Temperature
Temperature range 5°C above ambient temperature to [°C]: 300
Temperature variation at 150 °C [± K]: 3.8
Temperature fluctuation at 150 °C [± K]: 0.7
Heating-up time to 150 °C [min] 29
Recovery time after 30 seconds door open at 150°C [min]: 6
Air change data
Air change (approx.) at 150°C [x/h]: 18
Electrical data
Rated Voltage [V]: 400
Power frequency [Hz]: 50 / 60
Nominal power [kW]: 3.4
Unit fuse [A] 3x16
Phase (Nominal voltage) [ph]: 3~
Outer dimensions
Width net [mm]: 1235
Height net [mm]: 1025
Depth net [mm] :765
Wall clearance back [mm]: 160
Wall clearance sidewise [mm]: 100
Doors
Unit doors: 2
Internal Dimensions
Width [mm]: 1000
Height [mm]: 800
Depth [mm]: 510
Further Dimension
Interior volume [L]: 400
Net weight of the unit (empty) [kg]: 145
Permitted load [kg]: 90
Load per rack [kg]: 35
Environment-specific data
Energy consumption at 150 °C [Wh/h]: 1200
Fixtures
Number of shelves (std./max.): 2 / 10
