Performance Data Temperature
Temperature range 10°C above ambient temperature to [°C]: 300
Temperature variation at 150 °C [± K]: 1.2
Temperature fluctuation at 150 °C [± K]: 0.3
Heating-up time to 150 °C [min]: 18
Recovery time after 30 seconds door open at 150 °C [min]: 4
Electrical data
Rated Voltage [V]: 230
Power frequency [Hz]: 50 / 60
Nominal power [kW]: 1.3
Unit fuse [A]: 6.3
Phase (Nominal voltage) [ph]: 1~
Outer dimensions
Width net [mm]: 710
Height net [mm]: 735
Depth net [mm]: 605
Wall clearance back [mm]: 160
Wall clearance sidewise [mm]: 100
Doors
Unit doors: 1
Internal Dimensions
Width [mm]: 550
Height [mm]: 550
Depth [mm]: 385
Further Dimension
Interior volume [L]: 116
Net weight of the unit (empty) [kg]: 57
Permitted load [kg]: 150
Load per rack [kg]: 30
Environment-specific data
Energy consumption at 150 °C [Wh/h]: 340
Sound-pressure level [dB(A)]: 43
Fixtures
Number of shelves (std./max.): 2 / 5
