Jumo Wtrans T Mineral-insulated RTD temperature probe with flexible protection tube (-200 ~ +600 °C, Part No.: 00537805)

Order code: 902930/60-150-1006-0-0-000-0-10-000/000

Operating temperature in °C: -200 to +600 °C

Measuring insert: 1× Pt1000 in 3-wire circuit

Tolerance class according to DIN EN 60751: Without (not relevant)

Protection tube diameter D in mm: Without (not relevant)

Insertion length EL in mm: Without (not relevant)

Insertion tip: Without (not relevant)

Radio frequency: 868.4 MHz (Europe)

Process connection: Without (not relevant)

Extra code: Without

The Wtrans T is used in connection with a Wtrans receiver for stationary or mobile recording of temperatures within the operating range of -30 to +260 °C or -200 to +600 °C. This measured temperature value is transmitted wirelessly to the receiver of the Wtrans measuring system; here it is displayed and available digitally at the RS485 interface as well as an analog output.
