Jumo heatTHERM-AT Surface-mounted thermostat (0 ~ +50°C)

Order code: 603070/0001-5-021-671-000-000-70-00-2000-00-40-00-10-6-00-20-20-00-0/000

Basic type extension: Temperature controller (TR)

Type: Surface-mounted thermostat, with thermowell, flange sleeve, capillary, or as contact probe

Control range/limit value range 1 [°C]: 0 to +50 TR, TW

Control range/limit value range 2 [°C]: +70 to +130 STW, STB, Adjustable

Limit value 1 STW/STB: for adjustable control range

Limit value 2 STW/STB: for adjustable control range

Switching differential 1: 7 % of the scale range

Switching differential 2: Without switching differential (STB)

Capillary length 1: 2000 mm

Capillary length 2: 0 mm only for room thermostat

Material of capillary 1: Cu Copper

Material of capillary 2: Without capillary Single thermostat

Process connection: Plain cylindrical probe/contact probe

Diameter 1: Φ 6 mm

Diameter 2: Single thermostat

Probe material 1: CrNi Stainless steel

Probe material 2: CrNi Stainless steel

Capillary insulation: No protective tube

Insulation length (from case): No protective hose

Extra codes: Without extra codes

Image may be a representation. See Datasheet for product details.

The JUMO heatTHERM-DR (design type 7+8) type is a specific variation with a special case bottom section for DIN rail or wall mounting. As a result, easy installation on mounting rails TH35 according to DIN EN 60715 (e.g. in control cabinets) is possible.
