Jumo 901090 Screw-in melt thermocouples (-40~+400 °C/Metal braiding, Part No.: 00525149)

Order code: 901090/10-505-1042-152-4-10-26-153-11-3000/000

Operating temperature in °C/thermal line: -40 ... +400 °C/Metal braiding

Measuring insert: 1× Fe-CuNi "L"

Fitting length EL in mm: 152 mm (Standard)

Probe tip shape: Blade

Probe tip length L in mm: 10 mm

Material/surface of the probe tip: 1.4571 (Standard)

Process connection: 1/2" × 20 UNF

Thermal line end: Ferrules as per DIN 46228 Part 4 (Standard)

Thermal line length AL in mm: 3000 mm

Extra codes: None

Screw-in melt thermocouples are predominantly used to acquire temperature measurements for melt temperatures in the plastics industry.
