Jumo 608002 Dial Thermometer (0 ~ +120 °C, Part No.: 80001185)

Order code: 608002/0180-818-847-6-104-26-26-200/000

Display range (AB) in °C: 0 to +120

Process connection (PC): Protection tube with displaceable threaded fitting (max.20 bar)

Ø Process connection (PA): 6 mm

Thread type of process connection (PC): Screw connection G 1/2

Probe material: Stainless steel (CrNi, 1.4571)

Material of process connection (PC): Stainless steel (CrNi, 1.4571)

Insertion length, process connection (PC) dimension "S": 200 mm

Extra code (TZ): Without extra code

The measuring principle of the thermometer is based on a bimetal coil in a stainless steel or brass protection tube. If the temperature increases or falls, it turns and has a direct effect on the indicator via an axis.
