Dimensions and volumes:
Dimensions (W × L × H): 9.1 x 16.1 x 16.5 in.
Filling volume: 3 ... 4.5 l
Weight: 24.5 lbs
Pump connections: M16x1 male
Temperature values:
Working temperature range: +20 ... +300 °C
Temperature stability: ±0.01 °C
Setting the resolution of the temperature display: 0.01 °C
Temperature display resolution: 0.01°C
Ambient temperature 1: +5 ... +40 °C
Performance values: 230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)
Heating capacity: 2 kW
Pump capacity flow pressure: 16 …31 l/min
Circulation capacity pressure: 3.5 ... 13.3 psi
Maximum suction: -0.4 ... -5.8 psi
Viscosity max.: 70 cSt
Power consumption: 11 A
Bath:
Bath tank: Stainless steel
Bath cover: integrated
Usable bath opening (W x L / D): 5.1 x 5.9 / 5.9 in.
Cooling
Cooling coil: integrated
Other
Classification: Classification III (FL)
IP Code: IP 20
Pump function: Pressure Pump
Pump type: Immersion Pump
Electronics
Interfaces: Ethernet / Modbus / RS232 / RS485 / Stakei / Standby-Input / USB
External pt100 sensor connection: integrated
Integrated programmer: 8x60 steps
Temperature control: ICC
Absolute temperature calibration: 10 Point Calibration
Temperature display: 7" TFT Display
Temperature setting: Touchscreen
Electronic Timer (h:min): 00:00 ... 99:59
