Dimensions and volumes:
Dimensions (W × L × H): 13 x 19.3 x 18.5 in.
Filling volume: 8.5 ... 12 l
Weight: 26.9 lbs
Pump connections: M16x1 male
Barbed fittings inner diameter: 8/12 mm
Temperature values:
Working temperature range: +20 ... +150 °C
Temperature stability: ±0.03 °C
Setting the resolution of the temperature display: 0.1 °C
Temperature display resolution: 0.01 ... 0.1 °C
Ambient temperature 1: +5 ... +40 °C
Performance values: 230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)
Heating capacity: 2 kW
Pump capacity flow pressure: 15 l/min
Circulation capacity pressure: 5.1 psi
Viscosity max.: 50 cSt
Power consumption: 10 A
Bath:
Bath tank: Stainless steel
Bath cover: integrated
Usable bath opening (W x L / D): 8.7 x 5.9 / 7.9 in.
Cooling
Cooling coil: integrated
Other
Classification: Classification III (FL)
IP Code: IP 21
Pump function: Pressure Pump
Pump type: Immersion Pump
Electronics
Interfaces: USB
Temperature control: PID1
Absolute temperature calibration: 1 Point Calibration
Temperature display: LED
Temperature setting: Keypad
