X axis travel: 1100 mm
Y axis travel: 600 mm
Z axis travel: 610 mm
Spindle nose to table surface: 650 mm
Spindle center nose to column: 150 - 760 mm
Table work area: 1200 x 600 mm
Dimension of T-slot: CD 100 x 18 x 5T
Max. table load: 800 kg
Spindle taper / Bore diameter: BT50
Driving method: Gear Head
Spindle motor-cont / 30 min: 20 HP (Mitsubishi or Fanuc)
Spindle speed: 6000 rpm
Rapid feed rate - X / Y / Z: 20 x 20 x 18 m/min
X / Y / Z ball screw: 40 x 12B2 (dia. x pitch)
Max. tool length: 350 x 114.8 mm
Max. tool weight: 15 kg / 33 lbs
Number of tools: 24 pcs
Tool exchanging time: Bi-direction & Min Path
Gear ratio: 1:4.2
Bearings front: NN3018 (Ø90)
Bearings rear: NN3012 (Ø60)
Bearings lubrication: Grease
Preload: Rigid
Clamping force: 2000 kg
Coolant: Oil
Coolant requirement: 1500 keal/h
Min / Max. air pressure: 4 kg / 6cm²
Coolant tank capacity: 380 L
Net weight: 8500 kg
Gross weight: 8900 kg
Floor space requirement (L x W x H): 300 x 219 x 246 cm
Packing size (L x W x H): 310 x 228 x 250 cm
Container: 40"HQ
