X axis travel: 800 mm
Y axis travel: 600 mm
Z axis travel: 600 mm
Spindle nose to table surface: 150-750 mm
Spindle center nose to column: 600 mm
Linear way - X axis: RGW35
Linear way - Y axis: RGW45
Linear way - Z axis: RGW45
Ball screw - X axis: R40XP12
Ball screw - Y axis: R40XP12
Ball screw - Z axis: R40XP12
Table work area: 1000 x 600 mm
Max. table load: 400 kg
Dimension of T-slot: CD100 x 18 x 5T
Bore diameter: BT40
Spindle taper: ISO40
Spindle motor: 15 HP (Mitsubishi or Fanuc)
Spindle diameter: Ø70 mm
Belt: 10000 RPM
Directly (OP): 10000 / 12000 / 15000 RPM
Rapid feed rate (X / Y / Z): 36 / 36 / 24
Motor (X / Y / Z): 2.5 / 2.5 / 3.5 KW
Max. tool length: 250
Max. tool weight: 6 kg / 13.2 lbs
Number of tools: 240 pcs
Tool exchanging time: 10 / 4 sec
Min / Max. air pressure: 4 kg / 6cm²
Coolant tank capacity: 250 L
Net weight: 5200 kg
Gross weight: 5500 kg
Floor space requirement (L x W x H): 261 x 210 x 235 cm
Packing size (L x W x H): 265 x 228 x 245 cm
Container: 40"HQ
