JPT YDFLP-C-20-M7-S-R Mopa Fiber Laser (>20W/ 0.8mJ/ 1-4000kHz)

Application

Scribing, Drilling

Surface treatment

Sheet metal cutting, Welding

Marking on fly

Metal surface processing, Peeling coating

Specification

M²: <1.4

Armored Cable Length (m): 2

Nominal Average Output Power (W): >20

Maximum Pulse Energy (mJ): 0.8

Pulse Repetition Rate Range (kHz): 1 ~ 4000

Pulse Duration (ns): 2 ~ 350

Output Power Stability (%): <5

Cooling Method: Air Cooled

Supply DC Voltage (VDC) (V): 24

Maximum Power Consumption (W): <110

Environmental Supply Current (A): >5

Central Emission Wavelength (nm): 1064

Emission Bandwidth @3dB (nm): <15

Polarization Orientation: Random

Anti-high Reflection: Yes

Output Beam Diameter (mm): 7±0.5

Output Power Tuning Range (%): 0 ~ 100

Operation Temperature (℃): 0 ~ 40

Storage Temperature (℃): -10 ~ 60

Net Weight: 3.75 kg

Size(L×W×H): 245 × 200 × 65 mm

JPT M7 series high power pulsed fiber lasers make use of master oscillator power amplifier (MOPA) configuration, and show excellent laser performance as well as high level of temporal pulse shaping controllability. As compared to the Q-switching technology, the pulse repetition frequency (PRF) and pulse width can be controlled independently in MOPA configuration, through adjusting different combination of the above parameters, the peak power of laser can be well maintained. And enable JPT laser suitable for more material processing which Q-switch limited. The higher output power makes its advantages especially in high speed marking applications
