Technical Parameters：
Vickers hardness scale: HV0.2,HV0.3,HV0.5,HV1,HV2，HV2.5,HV3，HV5，HV10，HV20.HV30
Display: 4-digit hardness value, 4-digit diagonal length (D1, D2), holding time, number of tests, conversion scale, light brightness, test force
Test force (Kgf): 0.2, 0.3, 0.5, 1, 2, 2.5, 3, 5, 10, 20, 30kgf
Test mode: HV/HK
Objective lens and indenter switch: Automatic switching
Measurement magnification: Dual objective lens measurement can measure 10X and 20X
Loading control: Automatic (load/hold/unload）
Test force holding time (s): 1~98
Optical channel: Automatic (load/hold/unload
Optical system:
Objective lens: 10×, 20× (optional 40X) Eyepiece magnification: 10× (optional 15X)
Total magnification (μm): 100×, 200× Measuring range (μm): 400
Resolution (μm): 0.5
Execution standard: ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2
Hardness measurement range: (5-9999)HV
XY test table (optional)
Size (mm): 100×100 Travel range (mm): 25×25
Minimum reading (mm): 0.01
Maximum test piece height (mm): 165
Maximum test piece width (mm): 130 (Distance from the center line of the pressure head to the machine wall)
Power supply voltage: AC220V/50HZ
Dimensions (mm): 585×200×630
Weight (kg): 42
Standard Configuration
Main unit: 1 unit
Large and medium "V" test bench: 1 each
Horizontal adjustment screw: 4 pieces
Power cord: 1 stick
10X micrometer eyepiece: 1 piece
Vickers hardness block: 2 pieces
2A spare fuse: 2 pieces
Product certificate: 1 portion
Product instruction manual: 1 portion
Main functions and features of the machine:
1. The optical system designed by senior optical engineers not only has clear images, but can also be used as a simple microscope. The brightness is adjustable, the vision is comfortable, and it is not easy to get tired after long-term operation;
2. The industrial display screen can display the test method, test force, measured indentation length, hardness value, test force holding time, and number of measurements;
3. The cast aluminum shell is formed in one step, the structure is stable and does not deform, the car paint is high-grade, and the scratch resistance is strong. It is still bright as new after years of use;
4. Our company has the ability to independently develop, design, produce and process, and our machines provide lifetime parts replacement and maintenance upgrade services;
5. The CHV-30Z model can input the measured indentation length on the button to obtain the hardness value;
6. The CHV-30Z model can achieve: observation-test-measurement position switching is completed by the automatic turret;
Main uses and scope of application:
1. Steel, non-ferrous metals, metal foil, cemented carbide, metal sheet, microstructure, carburization;
2. Carburizing, nitriding and decarburizing layers, surface hardening layers, electroplating layers, coatings, heat treatment;
3. Glass, wafers, ceramic materials;
