Observe the head:
Binocular observation head, 45° tilt, pupil distance adjustment range 52mm-76mrn, with built-in interlocking mechanism, fixed eyepiece tube, with fixed setting and fixed doubling mechanism and ratio limit function design
Three-eye observation head, 45° tilt, pupil distance adjustment range 52mm-76mrn, with built-in interlocking mechanism, fixed eyepiece tube, with fixed setting and fixed doubling mechanism and ratio limit function design
The eyepiece:
High eye-point large field eyepiece PL10X/22mrn, adjustable visual Angle
High eye-point large field eyepiece PL15X/16mrn, adjustable visual Angle
High eye-point large field eyepiece PL20X/12.5, adjustable visual acuity
Objective: Continuous variable objective lens 0.67-4.5x, working distance 110mm
The auxiliary: 0.5X/177mm, 0. 7X/116mm, 1. 5X/47mm
Rack: One - piece vertical arm with mirror frame
Split column type, can be matched with any mirror frame Flat base
The base: Flat base/Lighted base
Photographic equipment: 0.35X / 0.5X / 0.65X / 1X camera connector, C-type interface
