Rated value
Input voltage: 0360V
Input current: 1mA30A
Input power: 150W
Range / Accuracy / Resolution:
Load accuracy:
0-36V: ±(0.05%+0.03%FS), 1mV
0-360V: ±(0.05%+0.03%FS), 10mV
0-3A: ±(0.05%+0.05%FS), 0.1mA
0-30A: ±(0.05%+0.05%FS), 1mA
Constant voltage mode:
1.5V-36V: ±(0.05%+0.03%FS), 1mV
1.5V-360V: ±(0.05%+0.03%FS), 10mV
Constant current mode:
0-3A: ±(0.05%+0.05%FS), 0.1mA
0-30A: ±(0.05%+0.05%FS), 1mA
Constant resistance mode:
0.05Ω~5Ω: ±(0.2%+0.2%FS), 0.001Ω
0.5Ω~50Ω: ±(0.1%+0.1%FS), 0.01Ω
5Ω~500Ω: ±(0.1%+0.1%FS), 0.1Ω
500Ω~5KΩ: ±(1%+1%FS), 1Ω
Constant power mode:
0-50W: ±(0.1%+0.1%FS), 1mW
0-150W: ±(0.1%+0.1%FS), 10mW
0-300W: ±(0.1%+0.1%FS), 0.1W
Voltage measurement accuracy:
0-9.9999V: ±(0.05%+0.03%FS), 0.1mV
10.000-99.999V: ±(0.05%+0.03%FS), 1mV
100.00-360.00V: ±(0.05%+0.03%FS), 10mV
Current measurement accuracy:
0-9.999A: ±(0.05%+0.05%FS), 0.1mA
10.000-30.000A: ±(0.05%+0.05%FS), 1mA
Battery test function:
Input voltage: 0.8~360V
Maximum capacity: 999A/H
Resolution: 0.1mA
Discharge time: 1~60000sec
Dynamic test mode:
T1 & T2 (A or B test time): 0.05mS~999S, Error＜2.5% +0.05mS
Protection range: ＞Rated condition 5%
Input impedance: ≧200kΩ
Dimension (WxHxD): 230mmx100mmx350mm
Weight: about 6 kg
Manual
Main feature:
■ Using ARM processor with high-speed sampling AD, the system runs smoothly and handy.
■ 360V wide voltage input, wider application range, can be widely used in non-isolated power supply testing.
■ The 4.3-inch TFT color screen has comprehensive display parameters, clear and intuitive, and supports Chinese and English operation interfaces.
■ U disk software update, U disk data saving and screenshot function (JK9930BU / JK9930CU).
■ Higher dynamic response speed for high-speed power supply testing.
■ Standard RS232 interface, can connect with computer without special cable.
■ Users can purchase standard RS232 to USB interface at will, without the need to purchase special connectors for manufacturers, saving costs for users.
