JINKO JK2519 Multichannel Resistance Tester (1μΩ－2MΩ)

Name: JINKO JK2519 Multichannel Resistance Tester (1μΩ－2MΩ)
Brand: JINKO

ManufacturerJINKO(View more products from this manufacturer)

ModelJK2519

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Measuring Parameter: DC resistance

Test Range: 1μΩ－2MΩ

Basic Accuracy: 0.05%

Range: Automatic and Manual (200mΩ, 2Ω, 20Ω, 200Ω, 2kΩ, 20kΩ, 200kΩ), 8 ranges

Temperature: PT100: -99℃ – 250℃, Accuracy: 0.3% * Measured Value ± 0.5℃

Measure Mode: Single-Machine, Scanning

Curve Mode: Template Value Contrast, Set Error, Temperature Resistance Curve

Test Parameter per Channel: Resistance

Scanning Channel: 15ch (4-wire system)/card, Maximum 8 cards/90ch, Each Channel of the Card is Scanning Test, Between Test Card is Synchronous Test, 8ch (4-wire system)/card

Test Selection of the Test Channel: Any Configuration Between Channels (Programmable)

Test Current: ≤100mA

Single CH Test Speed: 40 times/s, 2 times/s

8-Board Equivalent Test Speed: ≤4.3S

Temperature Compensation: Optional

Display: True Color 7.0 Inch LCD Display

Display Result: Display 32ch Test Result at the Same Time, Support Turn Page

Short Circuit Clear: All Channels Support Short Circuit Clear Zero in the Full Range

Comparator: Each Test Channel Can Be Set a Separate Limit

Limit Mode: ABS, %

Trigger Mode: Automatic Trigger, Manual Trigger, Handler Trigger, Foot Switch Trigger

Interface: LAN, USB HOST, RS232C, Handler

Test End: Four End Test

Power Supply: Voltage: 90-125V, 190-250V, Frequency: 50Hz/60Hz, Power: Max. 30VA

Datasheet

JK2518 multichannel resistance scanner creates a precedent for synchronous multi -channel testing! The simulation test scanning unit uses a synchronous card -type design concept. The supportable card board test unit can reach 6, and the synchronous measurement can be achieved between the card plates. Greatly improve the speed of scanning measurement. Each measuring board contains 15 testing end. The combination of the testing end supports users programming freely. The maximum can be configured with up to 90 resistance/temperature scanning measurement channels. Each channel measurement can be set separately to compare the boundaries and output comparative sorting signals. The maximum resistance accuracy of 0.05%, under the range of 200MΩ, the resistance resolution reached the level of 1uΩ. Test scanning range from 1UΩ to 2MΩ. The temperature compensation and temperature conversion function of the instrument make the product test from the impact of the environmental temperature. The comparison results of the entire machine level, board level, and various channels can be output, making your testing and data analysis processing and product sorting work easier. The standard RS232, USB Host, and Handler interfaces are convenient for you to save the measuring data rapidly, and it is convenient for your remote control instrument. The 24 -bit color and resolution of 800 *480 with a touch function, which brings a different feeling to your measurement operation!

Performance characteristics

■ Maximum of 90 channel resistance scanning test

■ The test end of the scanning test channel can be programmed

■ Multiple test units are measured synchronously (up to 15 units)

■ Compatible scanning and single-machine measuring mode

■ Each test unit can be inserted freely

■ Maximum resistance accuracy: 0.05%

■ Minimum resolution of the resistance: 1UΩ

■ The highest test speed can reach 80 times/second

■ Single -machine and scanning mode support resistance measurement

■ 7 -inch color LCD screen

■ Temperature compensation function (TC)
