Sensitivity 5.1mV/(m/s2) (50mV/G) ±10%
Frequency range (±3dB) 5 to 7,000Hz
Maximum measuring acceleration 490m/s2 (50G)
Shock survivability 9,800m/s2 (1,000G) Peak
Mounted resonance frequency 15kHz min.
Operating temperature range -10 to +80°C
Preserve temperature range -15 to +85°C
Weight 126g
Case material SUS303
Cable φ3 Coaxial cable (polyethylene-coated)
Mounting JIS M10, Length 7mm
Amplifier Preamplifier built-in
Excitation voltage +12 to +25VDC
Constant current excitation +0.4 to +5.1mA
Output bias voltage +4.75 to +9.20VDC
Electrical isolation Case isolated
Protection against ingress of water IPX7
