Ultrasonic sensor: Center frequency 40 kHz
Performance:
Leak source locating: Pressure 70 kPa / Able to detect leak from 0.2 mm hole in 7-meter distance
Partial discharge locating: Able to detect partial discharge 1000 pC equivalent in 3-meter distance
Analysis:
Time Waveform
Frequency Spectrum
Discharge Component Ratio
Mode:
Auto Mode: Auto Noise Identification, Gain Adjustment
Manual Mode: Items user selectable/adjustable
Detect area: Horizontally approx. 62° / Vertically approx. 35°
Display: 4.3 inch LCD / 800×480 pixels
Display Refreshment freq.:
High: About 8 times/sec
Eco: About 5 times/sec
About 3 times/sec (Partial Discharge Mode wave form displayed)
Other functions:
Loss Cost Estimation
Flow Adjustment
Peak Hold
Sleep Mode
Auto Power Off
Record contents:
JPG: Photo image, Image with Sound pressure map overlay
MP4: Video with Sound pressure map overlay onto image
CSV: Sound pressure map data, Measurement information list, Time waveform, Frequency spectrum
Storage Capacity:
Leak: Image Format 3,500 files
Partial Discharge: Image Format 3,000 files
Video Format: Up to 5 minutes/movie, Total within 30 minutes
Internal memory: 1 GB
The maximum records number of when only recording still images or only video
File Transfer: USB communication (PC with Windows OS required)
Power:
Rechargeable Lithium ion battery
Continuous use: Approx. 6 hours (normal temp.)
Size: W182 mm × H114 mm × D64 mm (Wrist strap and protector not included)
Weight: Approx. 740 g (including Lithium ion battery, Excluding wrist strap and protector)
Ingress Protection: IP42
Enclosed items:
Main Unit
Lithium ion battery (RRC2057)
Charger (RRC-SMB-MBC)
Wrist strap (MK-9907)
Protector (Blue) (MK-9910)
USB cable
User manual
Optional Accessories:
Lithium ion battery (RRC2057)
Neck strap (MK-9908)
Carrying case (MK-9705)
Waist bag (MK-9706)
Protector (Black) (MK-9909)
Oscillator for air/gas leak detection (MP-161-S001)
Oscillator for partial discharge detection (MP-161-S002)
