Control system Feedback control PID
Motion type Orbital or Reciprocating motion selectable
Frequency(RPM) 10 to 350
Timer Run time: 1 min to 999 hr 59 min 59sec
Forward & Backward, Pause: 10 sec to 59 min 59 sec
Amplitude size (mm / inch) 13 / 0.3
Overall (W×L×H)(mm/inch) 355×375×140 / 14.0×14.8×5.5
Net weight(Kg/lbs) 20 / 44.1
Electrical Requirements (230V, 50/ 60Hz) 0.2A
Cat. No. AAH3A215K
Wide selective models
- A wide selection of models to choose by:
- Shaking motion: orbital or reciprocating
- Maximum speed: 250, 300, 350, 400, 450, 500 rpm
- Amplitude: 7, 13, 19, 25 mm / 0.25, 0.5, 0.75, 1.0
Operating Features
Microprocessor PID control
- Additional shaking modes: (only for Orbital model)
- Forward (clockwise rotation)
- Backward (counterclockwise rotation)
- Pause
- Multi-step Programming of Shaking Operations:
- Delayed On/Off Timer: 10 sec to 999 hr 59 min 59 sec.
- Forward/Backward/Pause: 10 sec to 59 min 59 sec.
- Bright LED displays with touch-sensitive keypad
- Various optional accessories to accommodate diverse labware.
| Model |
SKF-2025 |
SKF-2050 |
SKF-2075 |
SKF-2025R |
SKF-2050R |
SKF-2050R |
Shaking
system |
Motion type |
Orbital |
Orbital |
Orbital |
Reciprocating |
Reciprocating |
Reciprocating |
| Spe edrange (RPM) |
10 to 500 |
10 to 400 |
10 to 300 |
10 to 450 |
10 to 350 |
10 to 250 |
| Accuracy at 100 RPM |
± 2
|
| Timer |
Delay On / Off Time : 1min to 999hr 59min
Forward & Backward, Pause : 10sec to 59min 59 sec
|
Amplitude size
(mm / inch) |
7 / 0.3 |
13 / 0.5 |
19 / 0.7 |
7 / 0.3 |
13 / 0.5 |
19 / 0.7 |
| Dimensions |
Platform (W×D)
(mm / inch) |
320×260 / 12.6×10.2
|
| Exterior (W×D×H) (mm / Inch) |
355×375×140 / 14.0×14.8×5.5
|
| Net weight (kg / Ibs) |
20 / 44.1
|
Electrical Requirements
(230V, 50/60Hz) |
0.2 A |
0.2 A |
0.2 A |
0.2 A |
0.2 A |
0.2 A |
| Cat. No. |
AAH3A105 |
AAH3A115 |
AAH3A125 |
AAH3A205 |
AAH3A215 |
AAH3A225 |
Electrical Requirements
(120V, 50/60Hz) |
0.4 A |
0.4 A |
0.4 A |
0.4 A |
0.4 A |
0.4 A |
| Cat. No. |
AAH3A106 |
AAH3A116 |
AAH3A126 |
AAH3A206 |
AAH3A216 |
AAH3A226 |
|
