Nominal Power: 370W
Peak power (Tool): 150W/Tool
Selectable temperature: 90 to 450 ºC / 190 to 840 ºF
Idle temp. stability (still air): ±1.5 ºC / ±3 ºF (Meets and exceeds IPC J-STD-001F)
Vacuum: 75% / 570 mmHg / 22.4 inHg
Flow rate: 9 SLPM
Temperature accuracy: ±3 %
Temp. adjustment: ±50 ºC / ±90 ºF (Through station menu setting)
Tip-to-ground resistance: <2 ohms
Tip-to-ground voltage: <2 mV RMS
USB-A:
Firmware update
Graphics and profiles
USB-B: PC communications
FAE / Robot connector: Remote control or FAE Fume Extractor connection
ESD safe: Meet ANSI/ESD S20.20-2021
Control Unit: 232 x 148 x 120 mm / 8.67 kg / 9.13 x 5.83 x 4.72 in / 19.11 lb
Package: 525 x 318 x 347 mm / 12.40 kg./ 20.67 x 12.52 x 13.66 in / 27.34 lb.
