James Heal TruBurst Pneumatic Bursting Strength Tester

Conditioned atmosphere recommended: Yes

Positioning: Bench standing

Space requirements: Width 40.0cm; Depth 52cm; Height 63cm

Approximate net weight: 69.3kg

Power: Single phase Yes; Rating per phase (A) 0.3; Watts 60

Compressed air: Pressure 10; Flow 50

Pressure range:

Upper pressure limit

kPa 1000

psi 145

kg/cm2 10.20

bar 10

kN/m2 1000

Resolution

kPa 0.2

psi 0.04

kg/cm2 0.002

bar 0.002

kN/m2 0.2

Distension range

Minimum

mm 0.1

cm 0.01

inches 0.004

Maximum

mm 70.0

cm 7.00

inches 2.756

Resolution

mm 0.1

cm 0.01

inches 0.004
