Rated parameter （0~40℃）
Input voltage: 0~500V
Input current: 0~15A
Input power: 250W
Min operating voltage: 0.8V/3A; 4.0V/15A
CV mode
Range: 0.1~50V; 0.1~500V
Resolution: L: 1mV; H: 10mV
Accuracy: ±(0.05%+0.05%FS)
CC mode
Range: 0~3A; 0~15A
Resolution: L: 0.1mA; H: 1mA
Accuracy: ±(0.05%+0.05%FS)
CR mode
Range: 0.3Ω~10Ω; 10Ω~7.5KΩ
Resolution: 16bit
Accuracy: 0.01%+0.08S; H: 0.01%+0.0008S
CP mode
Range: 250W
Resolution: 10mW
Accuracy: ±(0.2%+0.2%FS)
Measuring range
Voltage readback value
Range: 0~50V; 0~500V
Resolution: L:1mV; H:10mV
Accuracy: ±(0.025%+0.025%FS)
Current readback value
Range: 0~3A; 0~15A
Resolution: L:0.01mA; H:0.1mA
Accuracy: ±(0.05%+0.05%FS)
Power readback value
Range: 250W
Resolution: 10mW
Accuracy: ±(0.2%+0.2%FS)
Protected range
Over power protection: ≒260W
Over voltage protection: ≒3.3A; ≒16.5A
Over voltage protection: ≒530V
Over temperature protection: ≒85℃
Input terminal impedance: 1MΩ
Size(mm): 82*183*573
Weight: 5KG
