Rated values (0 °C - 40 °C):
CH1/ CH2/ CH3
Voltage: 0-30V/ 0-30V/ 0-5V
Voltage limiting: 31V/ 31V/ 6V
Current: 0-6A/ 0-6A/ 0-3A
Power: 180W/ 180W/ 15W
Load regulation(%of output + offset)
CH1/ CH2/ CH3
Voltage: ≤0.01%+3mV/ ≤0.01%+3mV/ ≤0.01%+3mV
Current: ≤0.01%+3mA/ ≤0.01%+3mA/ ≤0.01%+3mA
Line regulation (%of output +offset)
CH1/ CH2/ CH3:
Voltage: ≤0.01%+3mV/ ≤0.01%+3mV/ ≤0.01%+3mV
Current: ≤0.01%+3mA/ ≤0.01%+3mA/ ≤0.01%+3mA
Setup resolution:
CH1/ CH2/ CH3
Voltage: 1mV/ 1mV/ 1mV
Current: 1mA/ 1mA/ 1mA
Read-back resolution
CH1/ CH2/ CH3:
Voltage: 1mV/ 1mV/ 1mV
Current: 1mA/ 1mA/ 1mA
Setup accuracy (Within 12 months) (25°C ± 5 °C) (%of output + offset):
CH1/ CH2/ CH3:
Voltage: ≤0.03%+10mV/ ≤0.03%+10mV/ ≤0.03%+10mV
Current: ≤0.1%+8mA/ ≤0.1%+8mA/ ≤0.1%+5mA
Read-back accuracy(25 °C ± 5 °C) (%of output + offset):
CH1/ CH2/ CH3:
Voltage: ≤0.03%+10mV/ ≤0.03%+10mV/ ≤0.03%+10mV
Current: ≤0.1%+8mA/ ≤0.1%+8mA/ ≤0.1%+5mA
Ripple and noise (20Hz-20MHz)
CH1/ CH2/ CH3:
Voltage(Vp-p): ≤4mVp-p/ ≤4mVp-p/ ≤3mVp-p
Voltage(rms): ≤1mVrms/ ≤1mVrms/ ≤1mVrms
Current (rms): ≤5mArms/ ≤5mArms/ ≤4mArms
Output Temp. coefficient (0 °C ~ 40 °C) (%of output+offset):
CH1/ CH2/ CH3:
Voltage: ≤0.03%+10mV/ ≤0.03%+10mV/ ≤0.03%+10mV
Current: ≤0.1%+5mA/ ≤0.1%+5mA/ ≤0.1%+5mA
Read-back Temp. coefficient (0 °C ~ 40 °C) (%of output+offset):
CH1/ CH2/ CH3:
Voltage: ≤0.03%+10mV
Current: ≤0.1%+5mA
Series setup resolution:
CH1/ CH2:
Voltage: 1mV
Current: 1mA
Memory
Save/recall: 36 groups
Timer
Function: Output timer
Time set: 0.1 second-99999.9 second
Resolution: 0.1 second
Working temperature: 0-40°C
Dimension (Bare metal, mounted to the cabinet)W×H×D: 214.5mm×88.2mm×451.6mm
Dimension (Overall)W×H×D: 255.3mm×108.7mm×471mm
Weight: 15Kg
