ITECH IT-N2121 Solar Array Simulator (80V/ 25A/ 800W)

Rated values:

Voltage: 0～80V

Current: 0～25A

Power: 0～800W

Resistance: 0～9.999Ω

Line regulation ±（%of Output+Offset）:

Voltage: ≤0.01%+2mV

Current: ≤0.01%+1.5mA

Load regulation ±（%of Output+Offset）:

Voltage: ≤0.01%+2mV

Current: ≤0.01%+1mA

Setup resolution:

Voltage: 10mV

Current: 1mA

Readback resolution

Voltage: 1mV

Current: 1mA

Setup accuracy

Voltage: ≤0.03%+20mV

Current: ≤0.05%+10mA

Readback accuracy

Voltage: ≤0.03%+15mV

Current: ≤0.05%+8mA

Ripple（20hz-20Mhz）:

Peak value: ≤300mVp-p/≤40mVrms

Sense: ≤2V

Programming response: ≤15ms

Power factor: ≥0.98

Max.input current: 11A

Protection: OVP/OCP

Communication interface: LAN/USB

Isolation(output to ground): 1500Vdc

Isolation(input to ground): 1500Vac

Working temperature: 0～40℃

Fuse specification: T15A

Protection level: IP20

Safety regulations: IEC 61010

Cooling: fan

Dimension ( rack mounted ) mm: 450 mm（D）x 214 mm（W）x 88.2 mm(H)

Dimension (overall) mm: 529.5 mm（D）x 255 mm（W）x 108.2 mm(H)

Weight(net) : 9kg
