Basic
Resolution: 1280 × 1024
Max. Frame rate: 60 fps
Shutter Mode: Global
Mono/Color: Mono
Lens Mount: M12, auto focus
Trigger Mode: Software/external/free run etc.
Software: EasyVS
Certifications: CE、KC
Function: AI Tool: Classification Positioning: pattern match, line match, circle match; Inspection：profile contrast, pixel counting, brightness , contrast; Identification：1 dimensional and 2 dimensional codes； Logic Tool: mathematical logic operation
Focal Length: 7 mm
Focus Control: Auto focus
Light Source Type: White (Red & Blue options) , 1-channel diffused and 2- channel transparent light
Performance
Working Distance: 50-500mm
Field of View: 116×92 mm @150mm
Port
Connector: 2 industrial M12 connectors, Ethernet and GPIO
Network Port: 100M Ethernet
GPIO Interface: RS232, 2 Opto-isolated inputs，3 Opto-isolated outputs
Communication Mode: RS232, Ethernet
Communication protocol: TCP Client,TCP Server,UDP,FTP,RS232,Profinet,EtherNet/IP
LED Indicator: Power, Ethernet, Result
Power
Power Supply: Support 9~26VDC, 1.5A input
Power Consumption: <14W
Structure
Product Dimensions: 47mm×58mm×38mm (excluding connectors)
Net Weight: <180 g
Protection: IP65
Casing Material: Aluminum alloy (excluding front cover)
Environment
Operating Temperature: -20℃～+50℃
Operating Humidity: 20%～95%, non-condensing
Storage Temperature: -30℃～+70℃
