Basic
Resolution: 3072 × 2048
Max. Frame rate: 15 fps
Sensor Type: 1/1.8"CMOS
Shutter Mode: ROLLING
Pixel Size: 2.4 μm × 2.4 μm
Mono/Color: Mono
Lens Mount: C-MOUNT
Trigger Mode: Software trigger/Hardware trigger/Free run mode
Software: EasyID
Certifications: CE，UKCA，KC
Function: 1D:Code 39，Code 93，Code128，CodaBar，EAN8，EAN13，UPCA，UPCE，ITF25，2of5（Industrial2of5），standard25，GS1-128 ect； 2D:QR/Data Matrix/MQR/GS1 DM/GS1QR ect）；
Code quality evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416；
Performance
Max. Read Speed: 60 codes/s
Port
Connector: 2 industrial connectors: 1 Ethernet, 1 GPIO
Network Port: 1 GigE
GPIO Interface: 12-pin IO interface: 2 Opto-isolated inputs, 3 opto-isolated outputs
Communication Mode: 1 RS232, 1 GigE
Communication protocol: SDK，TCP Client，TCP Server，FTP，RS232，Profinet、Modbus、EtherNet/IP、MC(SLMP)、FINS/UDP、FINS/TCP
LED Indicator: 5 status indicators: system, network,trigger and 2 user configurable indicators
Power
Power Supply: 24VDC
Power Consumption: ≤4.0W(Without light source)
Structure
Product Dimensions: 68mm×55mm×28mm(Excluding lens mount and connector)
Net Weight: <200 g
Protection: IP67(With lens cover installed correctly)
Casing Material: Aluminium alloy
Environment
Operating Temperature: -20℃～+50℃
Operating Humidity: 20%～95%，No condensation(Excluding lens mount and connector)
Storage Temperature: -30℃～+80℃
