Basic
Resolution: 1280 × 1024
Max. Frame rate: 60 fps
Shutter Mode: Global
Lens Mount: M12, auto focus
Trigger Mode: Software trigger/External trigger/Free run modes
Software: EasyID
Certifications: CE，KC
Function:
lD: Code 39/Code 93/Code128/CodaBar/EAN8/EAN13/UPCA/UPCE/ITF25/2of5（Industrial2of5）/standard25/GS1-128 etc. and 2D: Data Matrix/MQR/GS1 DM/GS1QR etc.;
Quality Evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416）
Performance
Focal Length: 12mm
Working Distance: 50-500mm
Field of View: 64×51 mm（working distance:150mm）
Max. Read Speed: 60 codes/s
Light Source Type: Blue （Difused/Polarized/Non-polarized）
Port
Connector: 2 Industrial connectors support Ethernet and GPIO
Network Port: 100M Ethernet
GPIO Interface: RS232, 2 Opto-isolated inputs and 3 Opto-isolated outputs
Communication Mode: RS232, Ethernet
Communication protocol: SDK,TCP Client,TCP Server,FTP,RS232,Profinet,Modbus,EtherNet/IP,MC(SLMP),FINS/UDP,FINS/TCP
LED Indicator: Power,Ethernet,Result
Power
Power Supply: 9~26V DC, 1.5A input, suitable for industrial environment
Power Consumption: <5W
Structure
Product Dimensions: 47mm×58mm×38mm(not including connector)
Net Weight: <180 g
Protection: IP65
Casing Material: Aluminum alloy + Front cover
Environment
Operating Temperature: -20℃～+50℃
Operating Humidity: 20%～95%(no condensation)
Storage Temperature: -30℃～+70℃
