Basic
Sensor: 2K
Image Sensor: CMOS
Shutter: Global
Resolution: 2048 × 2
Line Rate: 49 kHz
Bit Depth: 12
Mono/Color: Color
Pixel Size: 14 μm × 14 μm
S/N Ratio: >39dB
WDR: 66dB
Image Format: BayerRG8/BayerRG10/BayerRG12/RGB8Packed/YUV422Packed
ROI: Support
X Flip: Support
Gain: 1~32
White Balance: Support
Gamma: From 0 to 4，support LUT
Exposure Time: 8μs~100ms
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
FPN: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 64MB image cache，64MB data cache
Port
Port: GigE
GPIO Interface: 12-pin Hirose interface for external power supply and external triggering; 2 differential/single-ended inputs, 1 differential configurable input or output, 1 high-speed optocoupler single-ended input, 1 GPIO configurable input or output
Lens Mount: M42 x 1
Power
Power Supply: DC 12~24V power supply via 12-pin Hirose connector
Power Consumption: ≈4.5W
Structure
Product Dimensions: 62 mm × 62 mm × 44 mm (Not including rear case connector)
Net Weight: 245 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
