Basic
Sensor: PYTHON 25K
Image Sensor: 23.0 mm x 23.0 mm CMOS
Shutter: Global
Resolution: 5120 × 5120
Frame Rate: 43 fps
Bit Depth: 10 bit
Mono/Color: Mono
Pixel Size: 4.5 μm × 4.5 μm
Pixel: 25 MP
S/N Ratio: 41 dB
WDR: 58 dB
Image Format: Mono8/10/10Packed
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1 ~ 32
Gamma: 0 ~ 4，support LUT
Exposure Time: 35 μs ~ 15 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 1 GB
Port
Port: 10GigE
GPIO Interface: 3x Opto-isolated input, 3x Opto-isolated output, 1x RS232
Lens Mount: M58 x 0.75
Power
Power Supply: DC 24V power supply via 12-pin Hirose interface
Power Consumption: 24 V ≈ 21.6 W
Structure
Product Dimensions: 72 mm x 72 mm x 78.5 mm (not including rear case connector)
Net Weight: 583 g
Environment
Storage Temperature: -30℃ ~ 80℃
Operating Temperature: -30℃ ~ 50℃
