Basic
Sensor: Customized
Image Sensor: 11.27 mm × 10.24 mm CMOS
Shutter: Global
Resolution: 4096 × 3072
Frame Rate: 85 fps
Bit Depth: 12 bit
Mono/Color: Mono
Pixel Size: 2.5 μm × 2.5 μm
Pixel: 12 MP
S/N Ratio: 37.7 dB
WDR: 66.9 dB
Image Format: Mono8/10/12
ROI: Support
X Flip: Support
Y Flip: Support
Gain: Analog Gain: 1× ～ 2×，Digital Gain: 1× ～ 100×
Exposure Time: 8 μS ～ 5 S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Port
Port: CXP-6
GPIO Interface: 1× Opto-isolated input, 1× Opto-isolated output, 1× configurable input and output
Lens Mount: C-mount
Power
Power Supply: DC 24V power supply via 6 Hirose interface, support PoCXP
Power Consumption: 24V ≈ 7.8W
Structure
Product Dimensions: 50 mm × 50 mm × 44.8 mm (Non including rear case connector)
Net Weight: 240 g
Environment
Storage Temperature: -30℃ ～ 80℃
Operating Temperature: -30℃ ～ 40℃
